CAUTION:
Machine Damage Hazards — Pumped chemical systems, if not properly
installed, can cause corrosion damage.
� See the reference manual for precautions and additional information
before making any chemical connections.
2.1. Piped Inlet Specifications
BNWBUI02.R01 0000204404 A.3 A.2 9/21/18 11:31 AM Released
Table 1. Piped Inlets
Connection Description Source Requirements Piping Requirements, Comments
Cold water inlet 3/4" garden hose male
thread @ 10 - 75 psi
Pipe material per plumbing code
Hot water inlet
Flush water inlet
Steam inlet 1/2” NPT @ 30 - 115 psi
Liquid supply inlet 3/8" or 1/2" Flexible tubing as supplied by the
chemical supplier
2.2. Piped Outlet Specifications
BNWBUI01.R02 0000204323 A.3 A.2 9/20/18 4:18 PM Released
Table 2. Outlets
Connection Description Destination Requirements or Description Piping Specifications
Drain
3" pipe socket joint, unrestricted gravity feed
to sewer (external back pressure may extend
wash times - Do not reduce)
Rubber hose, PVC or
other approved materi-
al per plumbing code
Vent
3"
3. Power Connections and Precautions
BNWBUI01.C04 0000204322 A.3 9/21/18 2:37 PM Released
WARNING: Electrocution and Electrical Burn Hazards — Contact with electric
power can kill or seriously injure you. Electric power is present inside the
cabinetry unless the main machine power disconnect is off.
� Do not service the machine unless qualified and authorized. You must
clearly understand the hazards and how to avoid them.
CAUTION: Machine Damage Hazards — Voltage fluctuations of more than 10%
above or below the specified voltage for your machine can damage electri-
cal components, especially motors.
� Any such conditions should be corrected prior to commissioning your
machine.
Service Connections
