Milnor MWF77J7 - Door Assembly and Installation

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Add or remove
shims until the
door locks
properly and
seals.
Door Lock Cover
8
8
9,7
9,7
Hinge
B
A
AA
B
Door Installation
See
BMP130002.
5
MWF27J8, MWF27J8
Door Assembly and Installation
BMP130057/2013484A
(1/3)
1
4
10,11
Shims
Shims
76
