Pellerin Milnor Corporation
BPWMAB03.R01 0000166674 B.2 12/11/17 3:34 PM Released
Figure 1. Bearing Assembly Cross Section
Legend
A. Detail view of the bearing housing front
B. Detail view of the bearing housing rear
Bearing Housing Components MWF27
1 of 4
BPWMAB03 / 2017502A
BPWMAB03 0000166675 B.2 12/11/17 3:34 PM Released
60
