Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Components
all 1 98CMCR3015 MAIN BEARING ASSY=30X8 BEARING ASSEMBLY
all 2 15K215M CAPSCR M16X40 CLS 10.9 Z
all 3 15U316M FLTWASH D16 HARD HV200 D16 Z
all 4 20C007G THDLOCKSEAL LCT24231 RMUBL50CC
all 5 02 03258 GASKET=SHELLBACK LINER,3022H
all 6 02 03279 DOUBLER=SHELLBK LINER,3022H
all 7
15K032MS BUTSOKCAP SCR M6*20 SS
all 8 15U137 FLTWSHR M6-1 18-8 SS
all 9 20C005 ADH/SEALANT 50CC LCT#271-31
all 10 20C040B SUPERFLEX CLR RTV SIL 10.1OZ
all 11 15K180M M10-1.5X50HX HD CAP SCR DIN931
all 12 15U266 FLATWASHER 1"0DX7/16"IDX3/16"
all 13 15G206M HEX NUT M10 ZINC
all 14 98CMCR0949 COVER SHAFT RETAINER METRIC
all 15 98CMCR0950 SHAFT RETNR SPACER METRIC
all 16 15B201 HEXCAPSCR M20-2.5 X 50M 18-8
all 17 15K232 HEXCAPSCR 3/4-10UNC2X2 GR5 ZIN
all 18 98CMCR3023 SHAFT RETNR SPACER=3022X CSM
all 19 15K127M HEXFLGSCR 3/8-16 X2.5 GR8 ZINC
Bearing Installation MWF27
4 of 4
BPWMAB04 / 2017502A
BPWMAB04 0000168667 A.2 12/11/17 3:42 PM Released
