Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers(1, 2,3, etc.)assignedto componentsrelate theparts listtothe illustration.
Parts List—Door Assembly
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 02 03229A 30" SHELL DOOR
all 2 02 03251 DOOR GLASS, 3022H7
all 3 02 03200 DOOR GASKET, 3022H7
all 4 98CMCR0925 ASSY=DR HNDL MECH
all 5 98CMCR0971 DOOR INTERLOCK ASSY V8Z VRJ MILNOR ASSY A33 03226B
all 7 02 03260 30" SHELL DOOR HINGE RIGHT
all 8 15K031 BUTSOKCAPSCR 1/4-20X1/2 SS18-8
all 9 02 03260A 30" DOOR HINGE LEFT
all 10 27A271 .843"ID X 1.496" BASE CAP NCS36
all 11 27A270 .843"ID X 1.496" BASE NCS35
R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
BMP130057/2013484A
(3/3)
