24 M12 160x120 Thermal Imager Operator’s Manual
VISUAL IMAGING
Visual digital camera resolution 1.3 Megapixels
Field of View 56º Horizontal X 46º Vertical
Minimum distance in focus 11.8 in. (30 cm)
Focus method Fixed
Exposure control Auto
LED ashlight3 User-selectable on or off
GENERAL
Battery system
MILWAUKEE M12 Series rechargeable Li-Ion removable battery and M12 Series
drop-in battery charger
Image storage system
Removable 2 GB SD card installed, room for >300 image sets. The Thermal
Imager is tested to accommodate up to 32GB SD card (>4,800 image sets).
Data communication interface Mini USB with rubber ap called the media door to seal out dust and water
Display Color TFT-LCD 3.5 in. (9 cm) measured diagonally
Note 1: For the M12 rechargeable battery temperature and humidity ranges, refer to its Operator’s Manual
Note 2: The Thermal Imager displays readings <10°C and >350°C, but these readings are not specied
Note 3: THe LED oodlight does not affect thermal images
