M12 160x120 Thermal Imager Operator's Manual 23
PHYSICAL AND ENVIRONMENTAL
Drop test 3’ (1m) drop to concrete
Operating temperature range 14°F to 122°F (-10°C to +50°C)
Operating and storage humidity range 10% to 90%, non-condensing
Storage temperature range without battery1 -13°F to 140°F (-25°C to +60°C)
TEMPERATURE MEASUREMENT
Infrared (IR) resolution 160 X 120 pixels (picture elements, or data points)
Object temperature range2 14°F to 662°F (-10°C to 350°C)
Thermal sensitivity 0.1°C per 30°C Noise Equivalent Temperature Difference (NETD)
Spatial resolution 2.7 mrad Instantaneous Field of View (IFOV)
Accuracy ±4°F (2°C) or ±2% or reading, whichever is greater
On-board adjustable emissivity Variable from 0.01 to 1.00, in increments of 0.01
Infrared (IR) detector type Uncooled microbolometer focal-plane array (FPA)
Spectral range 8 to 14 μm
THERMAL IMAGING
Field of view (FOV) 25° Horizontal X 19° Vertical
Focus method Manual
Minimum distance in focus 3.9”.(10 cm)
Screen refresh 60 Hz
