Minarik DLC600 - Figure 11 Leader-Follower Connections with a Leader Encoder


DLC Series

OPTICAL
ENCODER
LEADER SHAFT
0 - 1800 RPM
FOLLOWER
MOTOR
MAGNETIC PICKUP
(NON-POLARIZED)
RUN-STOP SWITCH
OPEN TO RUN
CLOSE TO STOP
MODEL DLC600
INPUT 115/230V AC, 50/60 Hz, 50 mA
MINARIK DRIVES, SOUTH BELOIT, IL 61080
www.minarikdrives.com
G L1 L2 S1 S2 Fin + IN C INH
AC LINE
VOLTAGE
EARTH GND
115 VAC
or
230 VAC
COMMON +5 VDC OR +12 VDC SIGNAL FROM WIPER TERMINAL FROM CCW TERMINAL
NON-REGENERATIVE DRIVE
REGENERATIVE DRIVE
XP-AC DRIVE
S1
S0
S2
S2
S2
S1
