Mindray BeneHeart C2

2 - 4
2.4.2 Bottom View
The battery compartment provides the following connectors.
2.4.3 Back View
(1) USB connector: connects the USB flash memory.
(2) micro USB connector: connects the computer.
(3) Network connector (for equipment configured with the cellular module):
connects the SIM card.
(4) Battery compartment: stores the battery.
(1)
(2)
(3)
(4)
(1) Multifunction connector (for equipment configured with the CPR sensor:
connects the CPR sensor.
(1)
