Record
The thermal recorder records patient information, measurement numerics, up to three waveforms, etc.
Starting and Stopping Recordings
To manually start a recording:
Select the
hardkey on the front of either the patient monitor
or the recorder module.
Select the [Record] button from the current menu or window.
Automatic recordings will be triggered in the following conditions:
Timed recordings will start automatically at preset intervals.
If both [Alarm] and [Alm Rec] for a measurement are set on, an
alarm recording will be triggered automatically as alarms occur.
To manually stop a recording:
Select the
hardkey again.
Select [Clear All Tasks] in the
[Record Setup] menu.
Recordings stop automatically when:
A recording is completed.
The recorder runs out of paper.
When the recorder has an alarm
condition.
Left view of T6, T8, T9 (For T5, the recorder
is located at the right side)
