SPECIFICATIONS
1. DISPLAY: 5 digit, 0.56" (14.2 mm) red sunlight readable LEDs, (-19999 to
99999)
2. POWER:
115/230 V Version (MP30/00)
AC Power: 85 to 250 VAC, 50/60 Hz, 15 VA
Isolation: 2300 Vrms for 1 min. to all inputs and outputs.
Working Voltage: 300 V.
24 V Version (MP30/01)
DC Power: 11 to 36 VDC, 11 W (derate operating temperature to 40°C if
operating <15 VDC and all three plug-in cards are installed)
AC Power: 24 VAC, ±10%, 50/60 Hz, 15 VA
Isolation: 500 Vrms for 1 min. to all inputs and outputs.
Working Voltage: 50 V.
3. ANNUNCIATORS:
B/G - Brutto/gross weight display
NET - Net weight display
T - Tare weight display
SP1 - setpoint alarm 1 is active
SP2 - setpoint alarm 2 is active
SP3 - setpoint alarm 3 is active
SP4 - setpoint alarm 4 is active
Units Label - software controlled weight units label backlight
4. KEYPAD: 5 keys
5. A/D CONVERTER: 16 bit resolution
6. UPDATE RATES:
A/D conversion rate: 20/readings sec
Step response: 200 msec. max. to within 99% of final readout value
(digital filter and internal zero correction disabled)**
700 msec. max. (digital filter disabled, internal zero correction enabled)**
Display update rate: 1 to 20 updates/sec
Setpoint output on/off delay time: 0.0 to 3275.0 sec
Analog output update rate: 0.0 to 10.0 sec
Max./Min. capture delay time: 0.0 to 3275.0 sec
7. DISPLAY MESSAGES:
“OLOL” - Appears when measurement exceeds + signal range.
“ULUL” - Appears when measurement exceeds - signal range
“. . . .” - Appears when display values exceed + display range.
“- . . .” - Appears when display values exceed - display range.
8. CONNECTION TYPE: 4 or 6 wire bridge
9. COMMON MODE RANGE (w.r.t. input common): 0 to +5 VDC
Rejection: 80 db (DC to 120 Hz)
10. SENSOR INPUTS:
* After 20 minute warm-up. Accuracy is specified in two ways: Accuracy
over an 18 to 28°C and 10 to 75% RH environment; and accuracy over a 0 to
50°C and 0 to 85%RH (non-condensing environment). Accuracy over the 0 to
50°C range includes the temperature coefficient effect of the indicator.
** The indicator periodically (every 12 seconds) imposes a 500 msec delay
to compensate for internal zero drift. If the delay affects applications where step
response is critical, it can be defeated. Set the display update to 20/sec to
disable. In this case, add a zero error of 0.2% FS to the 24 mV input range over
the 0 to 50°C span.
11. BRIDGE EXCITATION :
Jumper Selectable: 5 VDC @ 65 mA max., ±2%
10 VDC @ 125 mA max., ±2%
Temperature coefficient (ratio metric): 20 ppm/°C max.
12. LOW FREQUENCY NOISE REJECTION:
Normal Mode: > 60 dB @ 50 or 60 Hz ±1%, digital filter off
Common Mode: >100 dB, DC to 120 Hz (w.r.t. earth)
13. USER INPUTS (Logic Level): Three software defined user inputs, jumper
selectable for sink/source logic
Max. Continuous Input: 30 VDC
Isolation To Sensor Input Common: Not isolated
User Inputs are isolated from all option card terminals.
14. TOTALIZER:
Time Base: second, minute, hour, or day
Time Accuracy: 0.01% typical
Decimal Point: 0 to 0.0000
Scale Factor: 0.001 to 65.000
Low Signal Cut-out: -19,999 to 99,999
Total: 9 digits, display alternates between high order and low order readouts
15. CUSTOM LINEARIZATION:
Data Point Pairs: Selectable from 2 to 12
Display Range: -19,999 to 99,999
Decimal Point: 0 to 0.0000
16. SERIAL COMMUNICATIONS: (RS232 or RS485)
Isolation To Sensor & User Input Commons: 500 Vrms for 1 min.
Working Voltage: 50 V. Not Isolated from all other commons.
Data: 7/8 bits
Baud: 300 to 19200
Parity: no, odd or even
Bus Address: selectable 0 to 99, Max. 32 meters per line (RS485)
Transmit Delay: Selectable for 2 to 50 msec or 50 to 100 msec (RS485)
17. ANALOG OUTPUT :
Types: 0 to 20 mA, 4 to 20 mA or 0 to 10 VDC
Isolation To Sensor & User Input Commons: 500 Vrms for 1 min.
Working Voltage: 50 V. Not Isolated from all other commons.
Accuracy: 0.17% of FS (18 to 28°C); 0.4% of FS (0 to 50°C)
Resolution: 1/3500
Compliance: 10 VDC: 10 KΩ load min.
20 mA: 500 Ω load max.
18. SETPOINT OUTPUT: Two types of field installable cards
Dual Relay Card:
Type: Two FORM-C relays
Isolation To Sensor & User Input Commons: 2000 Vrms for 1 min.
Contact Rating:
One Relay Energized: 5 amps @ 120/240 VAC or 28 VDC (resistive
load), 1/8 HP @120 VAC, inductive load
Total current with both relays energized not to exceed 5 amps
Life expectancy: 100K cycles min. at full load rating. External RC snubber
extends relay life for operation with inductive loads
Quad Relay Card:
Type: Four FORM-A relays
Isolation To Sensor & User Input Commons: 2300 Vrms for 1 min.
Contact Rating:
One Relay Energized: 3 amps @ 250 VAC or 30 VDC (resistive load),
1/10 HP @120 VAC, inductive load
Total current with all four relays energized not to exceed 4 amps
Life Expectancy: 100K cycles min. at full load rating. External RC
snubber extends relay life for operation with inductive loads
19. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range: 0 to 50°C (0 to 45°C with all three plug-in
cards installed)
Storage Temperature Range: -40 to 60°C
Operating and Storage Humidity: 0 to 85% max. non-condensing
Altitude: Up to 2000 meters
20. CERTIFICATIONS AND COMPLIANCES:
ELECTROMAGNETIC COMPATIBILITY
Notes:
1. Self-recoverable loss of performance during EMI disturbance at 10 V/m:
Measurement error exceeds unit specifications
For operation without loss of performance:
Mount unit in a metal enclosure (Buckeye SM7013-0 or equivalent)
Route power and I/O cables in metal conduit connected to earth ground.
21. CONNECTIONS: High compression cage-clamp terminal block
Wire Strip Length: 0.35" (9 mm)
Wire Gauge Capacity: One 14 AWG solid or Two 18 AWG
22. CONSTRUCTION:This unit is rated for NEMA 4X/IP65 indoor use. IP20
Touch safe. Installation Category II, Pollution Degree 2. One piece
bezel/case. Flame resistant. Synthetic rubber keypad. Panel gasket and
mounting clip included.
23. WEIGHT: 10.4 oz. (295 g)
Immunity to EN 50082-2
Electrostatic discharge EN 61000-4-2 Level 3; 8 Kv air
Electromagnetic RF fields EN 61000-4-3
Level 3; 10 V/m
1
80 MHz - 1 GHz
Fast transients (burst) EN 61000-4-4 Level 4; 2 Kv I/O
Level 3; 2 Kv power
RF conducted interference EN 61000-4-6 Level 3; 10 V/rms
Simulation of cordless telephones ENV 50204 Level 3; 10 V/m
900 MHz ± 5 MHz
150 KHz - 80 MHz
Emissions to EN 50081-2
RF interference EN 55011 Enclosure class A
Power mains class A
200 Hz, 50% duty cycle
INPUT STATE
SOURCING INPUTS
22 K
ΩΩ
pull-down
SINKING INPUTS
22 K
ΩΩ
pull-up to +5 V
Active
V
IN
> 3.6 VDCV
IN
< 0.9 VDC
Inactive
V
IN
< 0.9 VDCV
IN
> 3.6 VDC
Input Range
Accuracy*
(18 to 28C)
Accuracy*
(0 to 50C)
Impedance Resolution
±24 mVDC
0.02% of
reading +3 µV
0.07% of
reading +4 µV
100 Mohm 16 V
1 µV
±240 mVDC
0.07% of
reading +40 µV
100 Mohm 16 V
10 µV
Max
Continuous
Overload
0.02% of
reading +30 µV
