MS50SF7
Specification V1.0
www.minewsemi.com minewsemi@minew.com Copyright
©
Shenzhen Minewsemi Co., Ltd.
This manual and all the contents contained in it are owned by Shenzhen Minewsemi Co., Ltd. and are protected by Chinese laws and applicable international conventions related to
copyright laws.The company has the right to change the content of this manual according to the technological development, and the revised version will not be notified otherwise.
Without the written permission and authorization of the company, any individual, company, or organization shall not modify the contents of this manual or use part or all of the
contents of this manual in other ways. Violators will be held accountable in accordance with the law.
- 9 -
6 Pin Definition
Pin Number
Symbol
Type
Description
1
ANT
External
antenna
pins
Using the module's built-in antenna, this pin is directly
suspended.
If not using the built-in antenna of the module, an external
antenna can be connected through this pin. When using an
external antenna, the resistor that is connected to the
antenna needs to be horizontally soldered to this pin.
11
VDD
Power
source
Power supply: 1.7V-3.6V, short-circuit VDD and VDDH to
use the pin to supply power
2/9/18/26/33-38
GND
Ground
Ground
3/28
SWCLK/SWDIO
Debug
Debug, when debug only need to connect power supply pin,
ground and these 2 pins.
4-8/10/12-17/19-25
/27/29-32
P0.0-P0.1/
P0.3-P0.10/
P0.12-P0.18/
P0.20-P0.21/P0.25/
P0.28-P0.31
I/O
I0 port for general purpose
