5 Power button ( )
–
Press to turn on the product.
–
Press and hold to turn off the product.
6 Status LED
Displays the operating status of the product.
Refer to "Checking the status LED" for
more information.
7 Microphone button ( )
–
Press to turn audio recording on or off.
–
Press and hold to turn voice recognition on
or off.
8 Bluetooth button (
)
–
Press to turn on Bluetooth.
–
Press and hold to start initial Bluetooth
pairing.
–
When Bluetooth is on, press it again to turn
off Bluetooth.
9 Recording button (
)
Press to take a picture or start manual recording.
Change between video or picture on the
ACE 3.0 Pro display: Settings > Camera
settings > Rec Button Action.
10 LCD touchscreen
11 microSD™ card slot
12 Microphone
Rear camera
1 Security LED
2 Rear camera lens
3 Rear camera mount
4 Rear camera cable connector
EN
7
