Position
Icon Meaning
The corresponding icon
shows the mounts for the
lower LATCH anchors.
Seats equipped with lower
mountings are marked with
a pair (2) of LATCH icons.
For vehicles equipped with
a middle seat:
It is not recommended to
use the inner lower mount-
ings of standard outer
LATCH positions to fasten
a child restraint system on
the middle seat. Use the ve-
hicle seat belt instead for
the middle seat.
Before installing LATCH child
restraint systems
Pull the seat belt away from the area of the
child seat mountings.
Assembly of LATCH child restraint
fixing systems
1. Mount child restraint system, see manu-
facturer's information.
2. Ensure that both LATCH anchors are
properly engaged.
Child restraint systems with tether
strap
Safety information
Warning
If the upper retaining strap is incorrectly
used for the child restraint system, the
protective effect is reduced. There is a risk
of injury. Ensure that the upper retaining
strap is guided to the upper attachment
point without twisting and not over sharp
edges.
Warning
If the rear seat backrest is not locked, the
protective effect of the child restraint sys-
tem is limited or nonexistant. In certain
situations, for instance braking maneuvers
or in case of an accident, the rear seat
backrest can fold forward. There is a risk
of injury or danger to life. Make sure that
the rear seat backrests are locked.
Warning
The mounts for the lower mountings and
attachment points of the child restraint
system are intended for attaching child re-
straint systems only. If other objects are
attached, the mounts or attachment points
can be damaged. There is a risk of injury
or risk of damage to property. Only attach
child restraint systems at the correspond-
ing mounts for the lower mountings or at-
tachment points.
Attachment points
The respective icon shows the at-
tachment point for the upper retain-
ing strap. Seats with an upper top
Seite 95
Transporting children safely CONTROLS
95
Online Edition for Part no. 01405A7DAD4 - II/23
