• The symbol identifies hazardous conditions,
where the user must be referred to manual.
3. SPECIFICATION
3.1 General Specification
• Display: 3 1/2 digit liquid crystal display (LCD) with
maximum reading of 1999.
• Low Battery Indication: The “ “ indicator is
displayed when the battery voltage drops below
the operating level.
• Sensor Cover.
• Measurement Rate: 300ms nominal.
• Operating Environment: 0°C ~ 50°C, RH < 70%.
• Storage Environment: -20°C ~ 60°C, RH < 80%,
with battery removed from meter.
• Auto Power Off: 10 seconds.
• Standby Consuming Current: < 5µA.
• Battery: Standard 9V (NEDA 1604, IEC 6F22006P).
• Battery Life: 9 hours continuous typical (with la-
ser and backlight).
• Dimensions: 148(A) x 105(L) x 42(P)mm.
• Weight: Approx. 157g (including battery).
