MINIX NEO X5 at a glance
1. IR receiver
2. Power LED
3. Power button
4. Earphone jack
5. Microphone jack
6. USB port 1
7. SD/MMC card slot
8. OTG port (serves as
USB port 2 also)
9. Recover button (for
service and upgrade)
10. HDMI port
11. Optical audio port
12. USB 2.0 port 3
13. USB 2.0 port 4
14. Ethernet jack
15. DC 5V Power-in jack
3
15
14
11
2
10
12
13
4 5 6 7 8
9
1
