PARTS LIST
PARTS LIST
* This item is part of an assembly. This item cannot be sold separately due to machining and /or assembly that is required. P/N 2064939 REV. E ECN 31080 11-08
In the U.S.A., replacement parts may be ordered directly from MINN KOTA Parts Dept., 121 Power Drive, P.O.Box 8129, Mankato, Minnesota 56002-8129.
In Canada, parts may be ordered from any of the Canadian Authorized Service Centers shown on the enclosed list. Be sure to provide the model and seri-
al numbers of your motor when ordering parts. Please use the correct part numbers from the parts list. Payment for any parts ordered from the MINN
KOTA parts department, may be by cash, personal check, Discover Card, MasterCard or VISA. To order, call 1-800-227-6433 or FAX 1-800-527-4464.
Fuera de los Estados Unidos, consultar la lista anexa para ubicar el Centro de servicio autorizado
MINN KOTA. No dejar de incluir el número del MODELO y el número de SERIE del motor para el cual
se solicitan las piezas. Usar siempre los números de pieza correctos indicados en la lista de piezas.
1
2
3
4
5
6
7
8
9
11
14
17
18
19
20
21
22
23
24
25
26
28
29
30
31
*32
33
*34
*35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
2-100-278 ARMATURE ASSEMBLY 12v 3.25
788-015 RETAINING RING
2-200-079 HOUSING ASSEMBLY CENTER 3.25 TXT
2-300-132 BRUSH END HOUSING ASSEMBLY 3.25 SP.CO
2-400-187 PLAIN END HOUSING ASSEMBLY 3.25
880-003 SEAL
880-006 SEAL W/SHIELD
140-010 BALL BEARING
188-052 BRUSH ASSEMBLY [2.EA]
738-030 BRUSH PLATE W/HOLDER 3.25
975-032 SPRING- COMPRESSION [2.EA]
701-007 O-RING- THRU BOLT [2.EA]
701-039 O-RING MK406460
701-041 O-RING
830-001 SCREW- SELF THREAD 8-32X1.7 [2.EA]
830-078 THRU BOLT 8-32X8.0 [2.EA]
990-067 WASHER- STEEL THRUST
990-070 WASHER- NYLATRON [2.EA]
144-049 FLANGE BEARING (SERVICE ONLY)
2069241 MOTOR ASSEMBLY 12V 3.25 5SPC TXT
2032046 TUBE, COMPOSITE 36"
1378121 PROP W/DRIVE PIN, WASHER, NUT KIT
2061122 PROPELLER 3.25 HUB DIA
2151726 WASHER- 5/16 STD SS
2053101 NUT-PROP NYLOCK (MED) SS
2092600 PIN-DRIVE
2771818 BRACKET & HINGE ASSEMBLY (INCLUDES- 32—43)
2771910 BRACKET ASSEMBLY (INCLUDES- 32,34,35)
2061910 BRACKET
2060510 PIN-HINGE
2061300 SCREW-CLAMP [2.EA]
2011710 WASHER-CLAMP SCREW [2.EA]
2063605 T-BAR, PLASTIC
2062706 SPRING- (T-BAR)
2067201 LEVER-TILT BLACK
2061810 HINGE-PLASTIC
2037301 BUSHING-HINGE [2.EA]
2062800 TENSION BLOCK-SNAP IN
2011385 SCREW, TENSION/KNOB
2060515 PIN, TILT LEVER
2061520 COLLAR-DEPTH
2011365 SCREW-COLLAR/NEW KNOB
2050609 LEADWIRE (10 GA) W/SPADE TERM
2020703 SPADE TERMINAL 14GA HD [2.EA]
2026300 TIE WRAP
2062510 CONTROL BOX
2060214 CONTROL BOX COVER
2065640 DECAL COVER ENDURA 40
2064023 SWITCH-FWD/REV 5 SP
2033401 SCREW-10-24 X 1-3/4
2013110 NUT-10-24 HEX
2012100 SCREW-8-18 X 5/8 [6.EA]
56
57
58
59
60
2990919 INNER HANDLE ASSEMBLY
2060405 PIVOT, HANDLE
2012102 SCREW
2990929 OUTER HANDLE ASSEMBLY
2060009 FRONT BEARING
2883460 SEAL AND O RING KIT
