GENERAL MAINTENANCE
• Check battery charger for dirt, oil, battery corrosion, etc. Use a water and baking soda solution for cleaning corrosion. Wipe
clean using a dry cloth.
• Check clips for dirt, oil, and battery corrosion; then disconnect from battery posts and clean as necessary with water and
baking soda solution and dry with a clean cloth.
• When the charger is not in use, coil the power cord and output cord to prevent damage.
• When storing the battery charger, store in a clean dry area.
• If power cord or plug becomes damaged, you may contact the Minn Kota Service Repair Department for service repair
information. Otherwise, dispose of the battery charger in compliance with local law. Damaged cords and plugs can cause
electric shock or electrocution.
ELECTRICAL SPECIFICATIONS
Model Part No. System Volts
Output per Bank
(amps)
Total Output
(amps)
Input Current
(120VAC, 60Hz)
Input Power
(120VAC, 60Hz)
MK106D 1821065 12 6 6 1A 100W
MK210D 1822105 12 / 24 5 10 2.5A 200W
MK220D 1822205 12 / 24 10 20 4.4A 470W
MK315D 1823155 12 / 24 / 36 5 15 2.7A 270W
MK330D 1823305 12 / 24 / 36 10 30 5.2A 500W
MK330DS 1823304 12 / 24 / 36 10 30 5.2A 500W
MK440D 1824405 12 / 24 / 36 / 48 10 40 7A 620W
MECHANICAL SPECIFICATIONS
Model Part No. Banks Input Cable Output Cable Size L x W x H Weight (lbs)
MK106D 1821065 1 18AWG - 6" 16AWG - 6’ 8-3/4” X 4-3/4” X 3 4.5
MK210D 1822105 2 18AWG - 6" 16AWG - 6’ 11-1/2” X 7-1/2 X 4” 11
MK220D 1822205 2 18AWG - 6’ 16AWG - 6’ 13-1/2” X 7-1/2” X 4” 15
MK315D 1823155 3 18AWG - 6’ 16AWG - 6’ 12-1/2” X 7-1/2” X 4” 14
MK330D 1823305 3 18AWG - 6’ 16AWG - 6’ 16-1/4” X 7-1/2” X 4” 20
MK330DS 1823304 3 18AWG - 8.5’ 16AWG - 6’ 16-1/4” X 7-1/2” X 4” 20
MK440D 1824405 4 18AWG - 6’ 16AWG - 6’ 11-34” X 6-3/4” X 8” 22.5
DANGER
Damaged cords and plugs can cause electric shock or electrocution.
