6
Delimiter code
E When the above-mentioned command (+ data) + delimiter is inputted from the
control side, this product acts corresponding to the command and consecu-
tively outputs the error check code (+ data) + delimiter.
E The delimiter is CR + LF and the break point of the data is a comma.
E The input and output is carried out with a format of fixed length determined
for each command.
Error check code
E There are 11 kinds of error check codes as shown below.
OK00 : Normal operation
OK11 : Chromaticity measuring range over (same as E0 display)
OK12 : Luminance display range over (same as E9 display)
OK13 : Luminance display range under (same as flickering display)
ER00 : Command error
(A command other than above-mentioned command is inputted, out of the
parameter setting range)
ER01 : Setting error (same as E display)
ER11 : Memory value error (same as E1 display)
ER10 : Luminance and chromaticity measuring range over (same as E0 display)
ER12 : Luminance display range, chromaticity display range simultaneous
over (same as E9, E8 display)
ER19 : Display range over (same as E9 display)
ER20 : EEPROM error (same as E2 display)
(the value of the protect area of EEPROM is broken, cannot access
EEPROM, etc.)
ER30 : Battery out
(The power voltage same as B0 display is lower than BC voltage.)
