SPECIFICATIONS FOR MA-101 ACT AMPLIFIER
ITEM SPECIFICATIONS
1. FREQUENCY RANGE 620-865MHz
2. TONE SQUELCH 32.768KHZ
3. OSCILLATION MODE PLL-CONTROLLED
4. MAX. DEVIATION 40KHZ
5. ANTENNA Build in Antenna
6. SENSITIVITY 6dBuV at S/N over 70dB.
7. POWER SUPPLY 18VDC/ 100-240VAC Switching Power
8. POWER OUTPUT
27W(RMS)/4Ω(Load)
9. T.H.D. Less than 1%
10. FREQUENCY RESPONSE 80Hz-18KHz ± 3dB
11. SPEAKER Built-in 5 inch high sensitivity full range speaker
12. DIMENSION (m/m) 275X188X157
13. WEIGHTS 2.3 Kgs
14. COLOR Black
A101ACTI03A
