1.PARTSNAMEANDFUNCTIONS
DCIN18V
LINEIN
LINEOUT
CHARGE
ON
POWER
WIRELESSLEVEL
MIN MAX
OFF MAX
MICINLEVEL
(1)
(11)
(12)
(13)
(14)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(2)
(3)
(1)FixedHandle:Forconvenientcarryingbyhand.
(2)Speaker:Soundprojectsinthedirectionitispointed.
(3)Mic-InJack:Acceptsa6.3mm(1/4"plugwiredmicrophone.
(4)PowerSwitch/VolumeControl:Turnclockwisepasttheclickforpower-onand
volumecontrolforthewirelessmicrophone.
(5)PowerIndicator:Redlightilluminateswhenpoweristurnedontodenotenormal
powerstatus.GreenlightindicatesaRFlink(itisreceivingsignalfromthe
wirelessmicrophone).
(6)MicrophoneVolumeControl:Volumecontrolforthewiredmicrophone.
(7)ChargingIndicator:
(8)LineOut:Allowsyoutosendaudiosignal(AF)toanexternalamplifier.
(9)AuxiliaryInputJack:Usesa3.5mm(1/8""minijack"plug.Acceptsexternalaudio
inputs,suchasportablecassette/CD/MP3player.
(10)DCPowerInputJack:PlugintoDCcharger(supplied)forbatterycharging.The
innerconductorispositiveandshouldbeconnectedto18VDC10%,+2.5A.
(11)Body:Housesallelectroniccomponents.
(12)ShoulderCarryBelt:MaybestoredinsidetheBatteryCompartment.
(13)BatteryCompartment:Therechargeablebatteryislocatedbehindthebattery
compartmentdoor.
(14)MicrophoneStandMount:Forconvenientmountingonastandard35mmthreaded
microphonestand.
a)Redlightindicatesthebatteryisweakandneedscharging.Chargingtakesaminimum
of4hours.
b)Greenblinkinglightindicateschargingisinprogress.
c)Solidgreenlightindicatesthebatteryisfullycharged.
d)Thissystemisequippedwithanautocut-offcharger.Whenthebatteryisweak(red
light),powerwillcutoffautomaticallytoavoidanydamagethatcouldbecausedbya
powerover-drain.
(1)PersonalWirelessPASystem
(2)BatteryChargingProcedures:
a)TurnonPowerSwitch/VolumeControl(4).Redlight(5)shouldilluminate.
b)Turnonwirelesstransmitter.Greenlight(5)shouldilluminate.
c)Adjustvolumelevel(4)clockwisetodesiredloudness.
d)OnewirelessmicrophonecansimultaneouslytransmittomultipleMA-101units
receivingonthesamefrequency.However,multiplewirelessmicrophonesofthe
samefrequencycannottransmittoanMA-101receiveronthatsamefrequency.For
example,ifyouhavebothahand-heldwirelessmicrophoneandabody-pack
transmitteronthesamefrequency,besuretoswitchoffoneofthetwotoavoid
severeinterferencebetweenthem!
a)Pleasemakesurethebuilt-inrechargeablebatteriesarefullychargedbefore
andafteruse.Thebatteryitselfwillgraduallyself-dischargeoveralong
periodoftime.Therefore,ifthesystemwillnotbeusedforalongperiodof
time,pleasemakesurethebatteriesarefullychargedbeforestoringthem
properly.TheCompanywarrantyDOESNOTapplytoover-discharged
batteries;hence,pleaseensurethebatteriesarerechargedevery3months.
b)SimplyplugtheconnectorofthesuppliedDCadaptertotheDC18VPower
InputJack(10)andplugtheotherendintoanyavailableACsocket.
c)Chargingbeginsimmediately,andwillbeindicatedbyaflashinggreenLED.
IfthegreenLEDisnotflashing,itmayduetoexcessivepowerover-drain
anditmaytakelongerforthegreenLEDtoflash.Thisisnormalandnot
faulty.If,afterawhile,thereisstillnoflashinggreenLED,therechargeable
batterymaybefaulty.
d)Ifabatteryreplacementisneeded,openthebatterycompartmentand
exchangethefaultybatteryforanewone.Besuretoinsertthebatterywith
therightpolarityconnection.
e)Thebatteryisanexpendableitem and not covered by warranty.Undernormal
operation MIPRO offersaone-yearlimitedwarranty on the unit ONLY.
f)Ifyouexperienceashortoperatingtimeafterthebatteriesarefullycharged,
itisoftenanindicationofagingbatteries.Therefore,therechargeable
batteryshouldbereplacedassoonaspossibleatyourearliestconvenience.
2.OPERATINGINSTRUCTIONS
WirelessPortablePAAmplifierWirelessPortablePAAmplifier
