1.Whenmicrophoneisswitchedon:
Atthemomentofthepowerisswitchedon,theindicatorwillflashbriefly
indicatingnormaloperation.
SIGNALLEDindicatorofreceiverglows.
MoreLEDindicatorsshowsreceivedsignalstrengthisstrong.
AUDIOLEDdisplaysreceivedAFlevelfromthemicrophone.
(a)Whenpoweron:
(b)Afterpoweron:
(c)DuringUsage:
(d)Whenthemicrophoneisnotinuse:
Makesurethepowerofthemicrophoneisoff.Ifthemicrophonewill
notbeusedforsometime,pleaseremovethebatteriesfromthe
batterycompartmenttoavoidbatteryleakageandresultindamaged
batteryspringsandcircuit.Ifarechargeablebatterywasused,takeit
outandrechargeit.
1.Unscrewbatterycap(6)inacounter-clockwisedirection.
2.Insertwo1.5V(AA)batteryintothebatterycompartmentobservingthe
correctpolarity.Themomentthebatterytouchestheterminalsofthe
compartment,theindicatorwillflashbriefly.Thismeansthepolarityis
correct.However,ifnoflashoccurs,thisindicateswronginsertionor
batteryisdead.Pleasere-insertthebatteryobservingitscorrectpolarityor
changetoafreshbattery.
2.BATTERYINSERTION
(Fig.2)
3.OPERATINGINSTRUCTIONS
BodypackTransmitter
1.PARTSNAMESANDFUNCTIONS
5
6
8
7
4
1
2
3
(Fig.1)
1.AFInputJack:Connectstoalavaliereorheadsetmicrophone.(See5ways
ofconnectiononAFInputConnections)
2.PowerSwitch:SwitchtoONpositionforoperation.SwitchtoOFFposition
whennotinuse.
3.BatteryStatusIndicator:Indicatesthepoweron/offandbatterystatus.
(a)Whenpowerswitchisturnedon:TheLEDindicatorflashesbriefly,
indicatingnormalbatterystatus.
(b)WhenREDlightilluminatesateitherpoweronorduringusage:The
batterylevelislow,therefore,anewbatteryreplacementisthusnecessary.
4.TransmitterHousing:PackagesthePCBandbattery.
5.GainControl:Adjuststhedesirousinputgain.
6.GT/MTLevelSelector:SwitchGTpositionforelectricguitarusageONLY.
GainControlisirrelevantfor"GT".Switchto"MT"forcondenser
microphone,wiredmicrophone.GainControlworksin"MT"forinput
sensitivityadjusting.
7.BatteryCompartmentandCover:Accommodatestwo1.5V(AA)batteries.
HandheldWirelessMicrophone
