Mipro MA-101 - VHF Handheld Microphone Battery Insertion; VHF Handheld Microphone Operation; UHF Handheld Microphone Parts Identification

10 11
1.Whenmicrophoneisswitchedon:
Atthemomentofthepowerisswitchedon,theindicatorwillflashbriefly
indicatingnormaloperation.
SIGNALLEDindicatorofreceiverglows.
MoreLEDindicatorsshowsreceivedsignalstrengthisstrong.
AUDIOLEDdisplaysreceivedAFlevelfromthemicrophone.
(a)Whenpoweron:
(b)Afterpoweron:
(c)DuringUsage:
(d)Whenthemicrophoneisnotinuse:
Makesurethepowerofthemicrophoneisoff.Ifthemicrophonewill
notbeusedforsometime,pleaseremovethebatteriesfromthe
batterycompartmenttoavoidbatteryleakageandresultindamaged
batteryspringsandcircuit.Ifarechargeablebatterywasused,takeit
outandrechargeit.
1.Unscrewbatterycap(6)inacounter-clockwisedirection.
2.Insertwo1.5V(AA)batteryintothebatterycompartmentobservingthe
correctpolarity.Themomentthebatterytouchestheterminalsofthe
compartment,theindicatorwillflashbriefly.Thismeansthepolarityis
correct.However,ifnoflashoccurs,thisindicateswronginsertionor
batteryisdead.Pleasere-insertthebatteryobservingitscorrectpolarityor
changetoafreshbattery.
2.BATTERYINSERTION
(Fig.2)
3.OPERATINGINSTRUCTIONS
1.Grille:Protectscartridgeandprevents"POP"noise.
2.BatteryStatusIndicator:Indicatespoweron/offandthebatterystatus.
WhenthepowerswitchisturnedON,theredLEDsindicatorflashesbriefly,
indicatingnormalbatterystatus.Ifnoflashoccurs,itmeanseitherno
batterypowerorthebatteryisdischargedorinstalledincorrectly.Ifthe
indicatorstayslitafterpoweringon,itwarnsthebatterypowerislowand
shouldbereplaced.
3.PowerOn-offSwitch:Slidetheswitchforpower"ON"or"OFF".
4.Housing:Upperportionisconnectedtocapsulemoduleandbattery.
Internally,itholdstransmitterPCB.
5.BatteryCompartment:Designedtoaccommodateone9Vbattery.
6.BatteryCap:Coversthebatterycompartment.
7.Anti-rollRing:Forfrequencydifferentiation.
PUSHKNOBUPWARDTOTURNONANDDOWNWARDTOTURNOFF
TRANSMITTER.
1 2 3 4
5
6 7
Latestmodularizedmicrophonestructure.Built-in"NoiseLock"squelch
circuitryeliminates"pop"interference.
(Fig.1)
1.PARTSNAMESANDFUNCTIONS
HandheldWirelessMicrophoneHandheldWirelessMicrophone
