Mipro MA-101 - Handheld Wireless Microphone Guide; VHF Handheld Microphone Parts Identification

8 9
Note
1.Grille:Protectscartridgeandprevents"POP"noise.
2.BatteryStatusIndicator:Indicatespoweron/offandthebatterystatus.
WhenthepowerswitchisturnedON,theredLEDsindicatorflashesbriefly,
indicatingnormalbatterystatus.Ifnoflashoccurs,itmeanseitherno
batterypowerorthebatteryisdischargedorinstalledincorrectly.Ifthe
indicatorstayslitafterpoweringon,itwarnsthebatterypowerislowand
shouldbereplaced.
3.PowerOn-offSwitch:Slidetheswitchforpower"ON"or"OFF".
4.Housing:Upperportionisconnectedtocapsulemoduleandbattery.
Internally,itholdstransmitterPCB.
5.BatteryCompartment:Designedtoaccommodateone9Vbattery.
6.BatteryCap:Coversthebatterycompartment.
7.Anti-rollRing:Forfrequencydifferentiation.
PUSHKNOBUPWARDTOTURNONANDDOWNWARDTOTURNOFF
TRANSMITTER.
1 2 3 4
5
6 7
Latestmodularizedmicrophonestructure.Built-in"Piltone&NoiseLock"
dual-squelchcircuitryeliminates"pop"interference.
HandheldWirelessMicrophone
(Fig.1)
1.PARTSNAMESANDFUNCTIONS
