Mirage VENTUS ALPHA IVADH481A User Manual

52 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

CONFORMS TO

UL STD. 1995

CERTIFIED TO

CSA STD. C22.2

NO. 236

& INSTALATION MANUAL

IMPORTANT NOTE:

Read this manual carefully before installing

or operating your new air conditioning

unit. Make sure to save this manual for

future reference.

Please check the applicable models, technical

data, F-GAS(if any) and manufacturer information

from the “Owner’s Manual - Product Fiche ”

in the packaging of the outdoor unit.

ALPHA INVERTER

OWNER’S MANUAL

AIR-HANDLER AIR CONDITIONERS

MODEL

IVADH361A

IVADH481A

IVADH601A

OVADH361A

OVADH481A

OVADH601A

Table of Contents

Questions and Answers:

D
Derek DuncanAug 18, 2025
What to do if my Mirage VENTUS ALPHA IVADH481A Air Conditioner is not working?
- R
  reyesjasonAug 18, 2025
  If your Mirage Air Conditioner isn't working, first, check for a power failure and wait for the power to be restored. Ensure that the power is turned on. If the fuse is burned out, replace it. Also, the unit's 3-minute protection feature might be activated; wait three minutes after restarting the unit. Finally, check if the timer is activated, and if so, turn it off.
S
Sheri CrawfordAug 26, 2025
Why does my Mirage VENTUS ALPHA IVADH481A Air Conditioner start and stop frequently?
- A
  Allen SanchezAug 26, 2025
  Your Mirage Air Conditioner might start and stop frequently due to several reasons. There could be too much or too little refrigerant in the system; check for leaks and recharge the system with refrigerant. Incompressible gas or moisture might have entered the system; evacuate and recharge the system with refrigerant. A system circuit could be blocked; determine which circuit is blocked and replace the malfunctioning piece of equipment. The compressor might be broken; replace the compressor. The voltage could be too high or too low; install a manostat to regulate the voltage.
K
Katherine PerezSep 2, 2025
How to improve poor heating performance of Mirage VENTUS ALPHA IVADH481A?
- T
  torreskristenSep 2, 2025
  If your Mirage Air Conditioner has poor heating performance, consider these factors. If the outdoor temperature is extremely low, use an auxiliary heating device. Ensure that all doors and windows are closed during use to prevent cold air from entering. Low refrigerant levels due to a leak or long-term use can also cause this; check for leaks, reseal if necessary, and top off refrigerant.
