Mircom FX-350 Series - Panel Configuration;3. Correlation

FX-350/351 Series Programming Manual
17
The following is the list of process types for input modules which are items 5 and 6 in the device type menu.
The following is the list of process types for output modules which are items 7 and 8 in the device type menu.
Panel Configuration/Devices/4. Silenceable
This option allows configuring the circuit as silenceable or non-silenceable.
Panel Configuration/Devices/5. Second Stage
If configured as YES the input circuit will activate the second stage and the general alarm is activated
Panel Configuration/Devices/6. Label
If yes, then enter the label
This option allows affixing a label of a maximum of 20 characters to any device. This label is displayed on the
shared display when the device gets active or in trouble.
PANEL CONFIGURATION/3. CORRELATION
The user is prompted to enter the loop number and address of the device to be correlated
The list of all the output devices is then displayed to which the input device is correlated to or an empty list.
The user can press RIGHT arrow key to add and LEFT arrow key to delete an output device. When a user deleted
a device after the confirmation, the group is deleted and the list is updated. To add a device the user is prompted for
confirmation as shown below
Note: If Strobe is selected as the process type, make sure the proper strobe type is selected under the Panel
Configuration Features Menu.


3URFHVV7\SH
$ODUPSULR



:DWHUIORZ




$ODUPQYHU
6SYODWFK
6SYQODWFK
7URXEOH
0RQLWRU
5HP6ZL
---- Process type ---
1. Signal
2. Strobe
3. Relay
6LOHQFH DEOH"
>@
1
6HFRQGVWDJH"
>@1
>@
<
/DEHO"
(QWHUQHZQDPH
B
Ipt Dev Loop # & Addr
Loop :__ DevAddr :___
Correlation
LP:01 ADDR:004
LP:01 ADDR:006
LP:01 ADDR:008
