4 Mirka® Dust Extractor • 1230M & 1242 M • 230 V / 100–120 V • PC & AFC
Quick reference
Operating elements
1 Handle
2 Accessory positions
3 Container clamp
4 Wheel
5 Container
6 Inlet fitting
7 Switch
8 Speed control
9 Appliance socket
10 Filter cleaning button (Push & Clean)
11 Hose hook
12 Hose diameter setting
13 LED indicator
14 Inlet cap
The pictorial quick reference guide
The pictorial quick reference guide is designed to help you
when starting up, operating and storing the unit. The guide is
subdivided into four sections, which are represented by symbols:
Before starting
DO READ OPERATING INSTRUCTIONS BEFORE USE!
Control / Operation
A Flow rate and filter warning
B PC – Push & Clean filter cleaning system
C AFC– Auto Filter Cleaning system
D Cable and hose storage
E Hose insert & operations
F Case fastening accessory
Connecting electrical appliances
G Power tool adaption
Maintenance
H Filter bag replacement
I Filter replacement
J Motor cooling filter cleaning
K Gaskets and float cleaning
3
1
2
4
5
6
7
8
9
10
13
12
14
11
