Mission 529 USB Power Converter User Manual V1.0
- 4 -
Expansion
Up to two 529 units may be connected together
via the USB link to provide a maximum of ten 9V
pedal power outputs.
Connect the USB IN on the first 529 to a 2.1A –
2.4A output from a USB battery or power supply.
Connect the USB OUT from the first 529, to the
USB IN on the second 529 using a USB A-B cable.
Mounting
The 529 weighs 0.25lbs and can safely be
mounted to the top or underside of a pedalboard
using hook and loop tape. For free-standing use,
self-adhesive pads may be applied to the
underside of the enclosure.
WARNING: Do not attempt to connect more
than two 529 units together via USB as you
may exceed the current handling capacities of
the system.
WARNING: Do not attempt to dismantle the
enclosure, drill into the enclosure, or remove
and replace the enclosure screws. Doing so
could damage the unit, and may invalidate the
warranty.
