IP Rating Chart
TheIPCode(orIngressProtectionRating,sometimesalsointerpretedasInternationalProtectionRating)
consists of the letters IP followed by two digits.
FirstNumeral
Protection against the
ingress of solid particles
SecondNumeral
Protection against the
harmful ingress of water
IP
IP Requirements Example Protection of persons against
accesstohazardouspartswith:
0 Noprotection Non-protected
1 Fullpenetrationof50mm
diameter sphere not allowed.
Contactwithhazardousparts
not permitted.
Backofhand
2 Fullpenetrationof12.5mm
diameter sphere not allowed.
Thejointedtestngershallhave
adequate clearance from
hazardousparts.
12.5
Finger
3 Theaccessprobeof2.5mm
diameter shall not penetrate.
Tool
4 Theaccessprobeof1.0mm
diameter shall not penetrate.
Wire
5 Limited ingress of dust permitted
(no harmful deposit).
Wire
6 Totally protected against the
ingress of dust.
Wire
IP Requirements Example Protection from water
0 Noprotection Non-protected
1 Protected against vertically
falling drops of water. Limited
ingress permitted.
Verticallydripping
