Features of Your Sewing Machine
1
2
9
10
11
8
3
4
5
6
7
1
2
8
3
7
6
5
4
Front view
1. Take-up lever
2.Upperthreadtensiondial
3.Patternselectiondial
4. Thread cutter
5.Light
6. Needle clamp screw
7.Bottombobbin
8. Drawer
9. Hand wheel
10.Reversebutton
11.Power&speedswitch
Back view
1.Bobbinwinderpin
2.Bobbinwinderstop
3. Foot pedal input
4.Bobbinwindertensiondisk
5.Presserfootlifter
6.Presserfoot
7.DCinput
8. Spindle
