THREADING THE SEWING MACHINE
1. Threading upper thread
Caution: Always switch off the
appliance, disconnect the appliance
from the power supply and remove the
foot pedal when threading the machine.
(1) Turn the hand wheel to raise the needle to its
highest position.
(2)Putaspoolonthethreadspindle,putonthe
thread spindle cover and then pull out the
thread.
(3)Pullthethreadandletitpassthroughthe
bobbinwindertensiondisk.(mark
2
in the
pic.below)
(4) Guide the thread through the groove and
pull it up towards the chromed take-up lever.
(marks
3
&
4
inthepic.below)
(5) Feed the thread through the hole in the
chromed lever and pull it straight down
towards the needle. (marks
4
&
5
in the pic.
below)
(6) Feed the thread through the hole in the
needle holder, then through the eye of the
needlefromthefrontsidetothebackand
pullout10cmtotheback.(mark
6
in the pic.
below)
1
2
4
5
6
3
2.Replacingthebottombobbin
(1)Slidethebobbincoverbuttontotherightand
removethebobbincover(Fig.7).
(2)Putthenewbobbinintheholder,withthe
threadgoingclockwise.Leave10cmof
thread hanging out (Fig.8).
(3) Make a loop and put it in the hole under the
needle.
(4) Hold the end of the upper thread with
one hand, and turn the hand wheel
counterclockwise with the other hand, the
needlethreadwillpickupthebobbinthread
and pull it up through the hole under the
needle (Fig.9).
(5)Replacethebobbincoverandseparatethe
twothreadsandpullthemtothebackof
the machine under the presser foot, leaving
about15cmhangingthere.(Fig.10)
Caution:
• Always switch off the appliance,
disconnect it from the power supply
and remove the foot pedal when
replacing the bottom bobbin.
• Please use metal bobbins, otherwise
the magnetic holder cannot tense the
bobbin thread and work rightly.
