MiTAC 7521 N - Page 32

31
7521
7521
N/B MAINTENANCE
N/B MAINTENANCE
- Back-light unit : CCFL, 1 tube
- DC for Panel : 3.3V+-0.3V
- Pixel pitch : 0.279(H)X0.279(V)
- Power supply current : 320 mA (Typ)
- Lamp start Voltage : 1500Vrms (25 %)
1.5.2 HDD
 FUJITSU MHK2120AT : 12 GB Capacity
— 12.0GB Capacity
— Number of head : 3
— Number of cylinders : 14,784
— Bytes per sector : 512
— Recording method : 16/17 MTR
— Track density : 24,300 TPI
— Bit Density : 383 Kbpi
— Rotational Speed : 4,200 rpm +-1%
— Average Latency : 7.14 ms
— Interface : ATA-5 (Max. Cable length : 0.46 m)
— Data transfer rate :
— To/From Media : 12.5 to 22.3 MB/s
— To/From Host : 66.6 MB/s Max (Ultra-DMA mode 4)
— Data Buffer Size : 512 KB
— Spin up current : 0.9A
rms
— Max. Power Consumption : 4.5W (During spin up)
— Physical Dimensions (H X W X D) : 9.5 mm X 100.0 mm X 70.0 mm
— 15GB, 20GB, 24GB HDD To Be Defined.
