N/B MAINTENANCE
N/B MAINTENANCE
1.5.13 PCMCIA socket
 Operating temperature range : -55 %- +85 %
 Insertion force : 39.2N (MAX)
 10000 times insertion and withdrawal at the cycle rate 400- 600cycles/hour and no
 evidence of breakage and cracks on the component.
 In +85 % 250h life test conditions should be no evidence of breakage and
 Cracks on the component.
 In -55 % 96h life test conditions should be no evidence of breakage and
 Cracks on the component.
1.5.14 FAN
 Dimension : Made by Sunonwealth Electric Machine Industry Co. Ltd.
 Model number : KD0502PEB2-8 DC brushless fan
 Operating speed: 8000 rpm.
 Input voltage : 5V
 Operating temperature : -10 - +70 degree C.
 Weight : 7g
 Direction of rotation : C.C.W.
 Noise level : 27 dB(A)
 Rated power : 0.6 W
 Static pressure : 0.09 inch-H2O
 Air delivery : 2.3 CFM
