MiTAC 7521 N - Page 40

39
7521
7521
N/B MAINTENANCE
N/B MAINTENANCE
Note 1. LCD ID
LCD_ID2
LCD_ID1 LCD_ID0 Vendor PANEL
1 1 1 HUYNDAI 14X13
Description
Note 3. CPU & SDRAM Frequency setting table:
SW_FS3
SW_FS2 SW_FS1 SW_FS0 CPU SDRAM
0 0 0 0 66 100
0 0 0 1 100 100
0 0 1 1 133 100
0 1 0 0 66 133
0 1 0 1 100 133
0 1 1 1 133 133
1 0 0 0 66 66
1.6 Appendix 2: GPIO definitions
GPI DEFINITIONS
