MiTAC 7521 N - Page 88

87
7521
7521
N/B MAINTENANCE
N/B MAINTENANCE
6. Maintenance Diagnostics
6.
6.
3.1
3.1
Diagnostic Tools :
Diagnostic Tools :
LED * 8
LED * 8
PIO CONNECTOR * 1
PIO CONNECTOR * 1
PIN1 : STROBE PIN 13 : SLCT
PIN1 : STROBE PIN 13 : SLCT
PIN10: ACK# PIN 16 : INT#
PIN10: ACK# PIN 16 : INT#
PIN11: BUSY PIN 17 : SELIN#
PIN11: BUSY PIN 17 : SELIN#
PIN12: PTERR PIN 14 : AUTOFD#
PIN12: PTERR PIN 14 : AUTOFD#
PIN{9:2}: PD{7:0}
PIN{9:2}: PD{7:0}
6.
6.
3.2
3.2
CIRCUIT:
CIRCUIT:
PIO
PIO
CONNECTOR
CONNECTOR
LED
LED
1
1
13
13
14
14
25
25
P/N:411904800001
DESCRIPTION :PWA;PWA-378PORT DEBUG BD
Note:Order it from MIC/TSSC
OR
