BIOS Temp Sensor Name Explanation
CPU_Tctl_Value CPU Tempterature
SYS_Air_Inlet Sensor connected to the Front Panel
MB_Air_Inet Temperature of the M/B Air Inlet Area
SYS_Air_Outlet Temperature of the System Air Outlet Area
X550_Temp Temperature of Intel LAN X550 chipset
CPU_CORE_MOSFET Max Temperature of CPU_CORE_MOSFET
CPU_SOC_MOSFET Max Temperature of CPU_SOC_ MOSFET
DIMM_MOSFET_1 Max Temperature of CPU DIMM Area1 MOSFET
DIMM_MOSFET_2 Max Temperature of CPU DIMM Area2 MOSFET
P0_UMC0_CH_A Temperature of CPU0 DIMM Channel A
P0_UMC1_CH_B Temperature of CPU0 DIMM Channel B
P0_UMC3_CH_C Temperature of CPU0 DIMM Channel C
P0_UMC2_CH_D Temperature of CPU0 DIMM Channel D
P0_UMC6_CH_E Temperature of CPU0 DIMM Channel E
P0_UMC7_CH_F Temperature of CPU0 DIMM Channel F
P0_UMC5_CH_G Temperature of CPU0 DIMM Channel G
P0_UMC4_CH_H Temperature of CPU0 DIMM Channel H
CPU_FAN Fan Speed of CPU_FAN
SYS_FAN_1 Fan Speed of SYS_FAN_1
SYS_FAN_2 Fan Speed of SYS_FAN_2
SYS_FAN_3 Fan Speed of SYS_FAN_3
SYS_FAN_4 Fan Speed of SYS_FAN_4
SYS_FAN_5 Fan Speed of SYS_FAN_5
