16
Jumpers & Connectors
Connectors
1 Micro SD Connector (J19) 16 System Fan Connector (J21)
2 System Fan Connector (J42) 17 SATA Connector (J22)
3 NVMe/SATA M.2 Slot (CN3) 18 SATA Connector (J14)
4 IPMB Header (J67) 19 System Fan Connector (J17)
5 Front USB3.1 Header (J32) 20 2x12pin PWR Connector (J60)
6 TPM Header (J40) 21 PSMI Connector (J61)
7 NVMe/SATA M.2 Slot (CN1) 22 CPU Fan Connector (J34)
8 Front Panel Header (J38) 23 2x4pin PWR Connector (J63)
9 Slim SAS 8x Connector (CN4) 24 ID Button
10 Mini SAS HD Connector (J25) 25 Stacked USB3.1x2 + IPMI LAN5 (J51)
11 Mini SAS HD Connector (J26) 26 COM/VGA (J50)
12 Slim SAS 8x Connector (CN2) 27 LAN3/LAN4 (J16)
13 Mini SAS HD Connector (J27) 28 LAN2 (U93)
14 2x4pin PWR Connector (J65) 29 LAN1 (U8)
15 System Fan Connector (J18)
Slots LEDs
A PCI-E Slot (J12) i ID LED
B PCI-E Slot (J9) ii HDD Active LED
C PCI-E Slot (J11) iii BMC LED
D PCI-E Slot (J10)
E PCI-E Slot (J13)
Jumpers
a BMC COM Select (J55) e CMOS Clear (J36)
b Reset Select (J41) f ID Button Switch (J101)
c BMC Bypass Select (J43) g BMC COM Select (J56)
d FPGA JTAG Select (J39) h COM Port Select (J15)
