MiTAC TYAN S8030 - Page 19

http://www.tyan.com
19
CN2 (NVME0_1) / CN4 (NVME2_3): Slim SAS 8x Connector
Signal Name Pin Pin Signal Name
GND A1 B1 GND
NVME[0]/[2]_RX_P0 A2 B2 NVME[0]/[2]_TX_P0
NVME[0]/[2]_RX_N0 A3 B3 NVME[0]/[2]_TX_N0
GND A4 B4 GND
NVME[0]/[2]_RX_P1 A5 B5 NVME[0]/[2]_TX_P1
NVME[0]/[2]_RX_N1 A6 B6 NVME[0]/[2]_TX_N1
GND A7 B7 GND
NC A8 B8 CPU_HP_SMBUS_SCL[CN2/CN4]
NC A9 B9 CPU_HP_SMBUS_SDA[CN2/CN4]
GND A10 B10 GND
NVME[0]/[2]_CLK_DP A11 B11 NVME[0]/[2]_PERST_L
NVME[0]/[2]_CLK_DN A12 B12 NC
GND A13 B13 GND
NVME[0]/[2]_RX_P2 A14 B14 NVME[0]/[2]_TX_P2
NVME[0]/[2]_RX_N2 A15 B15 NVME[0]/[2]_TX_N2
GND A16 B16 GND
NVME[0]/[2]_RX_P3 A17 B17 NVME[0]/[2]_TX_P3
NVME[0]/[2]_RX_N3 A18 B18 NVME[0]/[2]_TX_N3
GND A19 B19 GND
NVME[1]/[3]_RX_P0 A20 B20 NVME[1]/[3]_TX_P0
NVME[1]/[3]_RX_N0 A21 B21 NVME[1]/[3]_TX_N0
GND A22 B22 GND
NVME[1]/[3]_RX_P1 A23 B23 NVME[1]/[3]_TX_P1
NVME[1]/[3]_RX_N1 A24 B24 NVME[1]/[3]_TX_N1
GND A25 B25 GND
CN2 Link CN4 SMBus_SCL A26 B26 NVME[0,1]/[2,3]_SCL
