9
System Monitoring
Chipset Aspeed AST2500
Fan Total (4) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Fan fail LED indicator, Over
temperature warning indicator, Fan
& PSU fail LED indicator
Others Watchdog timer support
Server Management
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size AMI, 32MB
Feature
Hardware Monitor, Boot from USB
device/PXE via LAN/Storage, User
Configurable FAN PWM Duty Cycle,
Console Redirection, ACPI sleeping
states S0, S5, ACPI 6.2, SMBIOS
3.2/PnP/Wake on LAN
Physical Dimension
Form Factor ATX
Board Dimension 12" x 9.9" (305 x 250.8mm)
Operating System
OS supported list
Please refer to our AVL support
lists.
Regulation
FCC (SDoC) Class A
CE (DoC) Class A
Operating Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Compliant Yes
Package Contains
Motherboard
(1) S8030
Motherboard
Manual
(1) Quick Installation
Guide
I/O Shield (1) I/O Shield
