9. Specifications
- Signal to Noise Ratio DAB @2Vp-p, with instrumental 20k LPF enabled. >85dB (A)
FM Ultimate signal to noise ratio 98MHz @60dBuV/75KHz Dev. Fmod=1KHz,
Amplitude=1.3Vpp Mono >75dB
- Total Harmonic Distortion (THD) DAB @2Vp-p with instrumental 20K LPF enabled <0.1%
FM 98MHz@60dBuV/75KHz Dev. Mono Fmod=1KHz, Amplitude=1.3Vpp
<0.5%
- Frequency Range DAB BAND 3: 5A 174.928MHz - 13F 239.200MHz
FM 87.5MHz - 108MHz
- Analog Outputs RCA/phono stereo left & right x 1
- Digital Outputs COAXIAL x 1,Optical TOSLINK x 1
- Control Interface RS232
- RF Input F Type connector (screw thread)(to VHF/FM diplexer) 50 ohms
- Power Supply AC 230V, 50/60 Hz
- Power Consumption Max 20W
- Dimensions (W x H x D) : 430 x 80 x 283 mm
- Weight Net 3.8kg Gross 5kg
- Output Level 700mV +/- 2dB @ 1KHz 0dB
- S/N Ratio (A) >80dB
- Power Supply AC 230V ~ 50Hz
- Max Power Consumption 20Watts
NOTE: Specifications and design are subject to possible modifications without notice
