1 Overview
The model MT150/MT160 is a digital ultrasonic thickness gauge. Based on the same operating
principles as SONAR, the instrument is capable of measuring the thickness of various materials with
accuracy as high as 0.1/0.01 millimeters. It is suitable for a variety of metallic and non-metallic
materials.
1.1 Product Specifications
Display：4.5 digits LCD with EL backlight.
Measuring Range：(0.75～300)mm (in Steel).
Sound Velocity Range: (1000~9999) m/s.
Resolution：MT150: 0.1mm; MT160: 0.1mm/0.01mm
Accuracy： ±（0.5%Thickness+0.04）mm, depends on materials and conditions
Units: Metric/Imperial unit selectable.
Four measurements readings per second for single point measurement, and ten per second for
Scan Mode.
Memory for up to 20 files (up to 99 values for each file) of stored values.
Power Source：Two “AA” size, 1.5 Volt alkaline batteries. 100 hours typical operating time (EL
backlight off).
Communication：RS232 serial port for MT160. No communication port for MT150.
Outline dimensions：150mm×74mm×32 mm.
