Clear Event Log
To clear the Event Log of its contents:
• Press the left or right arrow key to highlight the Clear Log field on the display.
• Press the “ENTER” key. A message will appear:
“PRESS ENT TO CLEAR THE EVENT LOG.”
• Press “ENTER” to purge the contents of the event log or press the “C” key to
return to the Status Screen.
3.2.7 SERIAL PORT REMOTE OPERATION SCREEN
If not already displayed, use the Up and down arrow keys to access the Serial port
remote operation screen.
The serial port remote operation screen allows the operator to configure the remote
control parameters listed below.
• RS485 (2-wire) or RS422 (4-wire) Bus
• RS485/RS422 or RS232 Remote Address
• RS485/RS422 or RS232 Baud Rate
• RS485/RS422 or RS232 Parity
↑
BUS: RS485 (2-WIRE)
↓
ADDRESS:65 BAUD
RATE:19200 PARITY:NONE
