MITJAVILA V2 - 11. Guide Installation; Install Guides and Place Load Bar

Page 11
11 Installation of the guides.
IN POSITION
A B
Right guide
Left guide
IMPORTANT, support the guides until the
installation of the front cassette.
C
Place the load bar on the guides.
Screw the guides.
2 x DIN912M8x20mm
+
washer
