Page 33
Simple span exploded view
1 Exploded section Guides
2 Exploded section Cassette assembly
3 PPV20 03 Wall prole cover
4 PPV11 02 Wall prole
5 JPV11 08 Wall prole nish cap
6 JPV11 07 Cassette assembly nish cap
7 JPV19 07 Front cassette nishing cap
8 PA29 Foot prole
9 ST38 Floor xing plate
10 PPV19 05 Front cassette prole
11 PPV20 03 Front cassette cover prole
No. Reference Description
1
2
7
5
3
6
4
8
9
10
11
