MITJAVILA V2 - 3. Wall Profile Installation (Over 7 m); Fixing the Left Wall Profile; Fixing the Right Wall Profile

Page 6
3 Fixing the wall prole. Pergola over 7m wide.
A
Fixing the left wall prole.
B
Place the right wall prole.
See paragraph 2 on page 5 for marking, drilling and xing operations.
C
Mark the position of the holes for the right wall prole.
D
Remove the right wall prole.
E
Drill at the marks for the right wall prole.
( Total width / 2 ) - 3mm
F
Fixing the right wall prole.
PLA1492M00I
PPV11 02
PPV11 02
Installation height
Installation height
( Total width / 2 ) - 3mm
