Mitox 25C SELECT - Assembly of the Grass Trimmer

25C SELECT Grass Trimmer
13
Original Instructions Version June 16
Assembly of the Grass Trimmer
The blade fitted to the guard is sharp and can cause injury, always wear gloves.
Installing the Guard
To install the guard to the shaft, locate the shield using bracket  as a locating point, and
secure using plate B and 2 screws.
Shaft
Guard
Bracket 
Plate B
