260B Blower / 280BV Blower Vacuum
6
Original Instructions Version July 12
Assembling the Vacuum
1.FittheVacuumelbowtubeoverthe
blower discharge port, aligning the
channels in the tube over the locking pin.
2. Twist the Vacuum elbow tube to engage
the locking pin as illustrated.
3.Lockthetubeinplaceusing1xM5x10
screw.
1.
2.
3.
Open the side cover using the
thumbscrew.
