455CSX / 515CSX PREMIUM Chainsaw
32
Original Instructions Version July 18
455CSX/515CSX_030718
455CSX Parts - Intake & Exhaust Assembly
NO. PART NO. DESCRIPTION QTY
43 MIA41.1113.0008-1 HOOK 1
44 MIA41.1113.0007-9 LOCK LEVER 1
45 MIA41.1113.0009-1 TRANSFER BAR 1
46 MI01.05.0242 PIN 3x22 3
47 MI01.05.0243 PIN 3x23 1
48 MIA41.1104.0002-1 LOCK KNOB 1
49 MIA50.5104.0001 LOCKING SPRING 1
50 MIA50.5104.0100 AIR FILTER 1
51 MIA38.0313.0004 AIR FILTER ABSORBER 1
52 MIA50.5113.0003-2 TOP COVER 1
53 MIA50.5113.0002 HEAT SHIELD 1
54 MIA50.5113.0001-8 BASE 1
55 MI01.01.3131 TAPPING SCREW ST4x10 6
56 MIA50.5113.0005-1 SCREEN 1
57 MIA50.5113.0102 COVER 1
58 MIA50.1113.0105 RUBBER ABSORBER 2
59 MIA50.5101.0016 SCREW M5x55 2
60 MIA50.5100.0009 TAPPING SCREW ST4.8x16 11
61 MIA50.5101.0500 AIR FILTER BASE 1
62 MIA50.1111.0010 THROTTLE CABLE 1
63 MIA41.1100.0010-12 CHOKE KNOB 1
64 MIA41.1100.0011 CHOKE KNOB BASE 1
65 MI06.08.02.1161A CARBURETTOR - WT1161 1
66 MIA50.1101.0017-1 THROTTLE CABLE ROLLER 1
67 MIA50.5113.0004 L/H GUIDE 1
68 MIA52.5101.0008 PIPE 1
69 MIA50.1101.0001 COPPER TUBE 1
70 MIA50.1101.0400-1 CARBURETTOR SUPPORT 1
71 MIA50.1101.0007 PRESSURE TUBE 1
72 MIA42.0101.0002 SUPPORT RING 1
73 MIA50.5101.0500 AIR FILTER BASE 1
74 MIA50.0101.0006 SPRING RING 1
75 MI03.01.2.153 PUMP PIPE ∅2.5x∅5x85 1
76 MIA38.0311.0100 PRIMER BULB 1
77 MIA50.5113.0006-2 REAR COVER 1
78 MIA50.5101.0100 ISOLATION CHAMBER 1
NO. PART NO. DESCRIPTION QTY
79 MIA52.5111.0011 PROTECTING JACKET 1
80 MIA50.1101.0101 INSET BUSH 2
81 MIA50.1105.0002 SHIELD 1
82 MIA50.1105.0004 MUFFLER GASKET 1
83 MIA50.1105.0300 MUFFLER 1
84 MI01.04.0121 PLAIN WASHER 2
85 MI01.04.0091 SPRING WASHER 2
86 MIA50.1105.0113 SCREW M5x20 12.9 2
87 MIA50.1105.0303-1 MUFFLER COVER 1
88 MIA50.1105.0005 SCREW M5x15 2
