CS38 SELECT - Base Unit Parts List
48 MIYD36.02.01-4 RECOIL SPRING 1
49 MIYD38-5.02.00-4 RECOIL HANDLE 1
51 MIGB/T845 ST4.8X19 TAPPING SCREW ST4.8X19 1
52 MIYD38-3.00.00-9 DUST COVER 1
53 MIYD38-3.06.04-00 ANTI-VIBRATION RUBBER 1
54 MIGB/T2672 M5X14 SCREW M5X14 5
55 MIYD38-3.06.03-00 ANTI-VIBRATION RUBBER 1
56 MIYD38-3.00.00-8 DUST COVER 1
57 MIYD38-3.00.00-4 ANTI-VIBRATION SPRING 1
58 MIYD38-3.00.00-1 LOOP HANDLE 1
59 MIYD38-3.00.00-13 COVER PLATE 1
60 MIGB/T845 ST4.8X25 TAPPING SCREW ST4.8X25 5
61 MIYD38-3.03.06-00 BREATHER ASSEMBLY 1
62 MIYD38-3.03.00-3 BREATHER GROMMET 1
63 MIYD38-3.03.05-00 FUEL PIPE ASSEMBLY 1
64 MIYD38-3.03.00-1 FUEL PIPE 1
65A MIYD38-3.03.00-1A FUEL RETURN PIPE 1
66A MIYD38-3.03.00-2A GROMMET - 1 HOLE 1
67 MIYD38-3.03.00-12 WEIGHT 1
68 MIYD38-3.03.04-00 FUEL FILTER 1
69 MIYD38-5.03.01-00 REAR HANDLE 1
70 MIYD38-3.00.00-5 ANTI-VIBRATION SPRING 1
71 MIYD38-6.03.02-00 FUEL CAP ASSEMBLY 1
75 MIYD38-6.03.03-00 OIL CAP ASSEMBLY 1
78 MIYD38-3.01.11.03-00 GROUND WIRE 1
79 MIYD38-3.01.11.04-00 ON/OFF SWITCH 1
80A MIYD38-3.03.00-4A PRIMER ASSY 1
81A MIYD45-4.03.00-13 FUEL PIPE 1
82 MIGB/T119.2 5X24 PIN 5X24 1
83 MIYD38-5.03.00-9 SAFETY LOCK TRIGGER 1
84 MIYD38-3.03.00-8 SAFETY LOCK SPRING 1
85 MIYD38-3.03.00-7 THROTTLE TRIGGER 1
86 MIYD38-5.00.00-6 THROTTLE LINK 1
87 MIYD38-5.03.00-10
HANDLE COVER 1
88 MIYD38-3.03.00-16 RETAINING CLIP 1
89 MIMIYD38-3.01.00-13 VENT PIPE 1
90 MIGB/T845 ST4.2X14 TAPPING SCREW ST4.2X14 1
91 MIYD38-3.01.06.00-00 WALBRO (JAPAN) CARBURETOR 1
92 MIYD38-3.01.00.03-00 INTAKE SCREW 2
93 MIYD38-3.01.00.02-00 AIR INTAKE SUPPORT 1
94 MIYD38-5.06.01-00 ENGINE BASE 1
96 MIYD38-3.07.00-00 GUIDE BAR COVER 14/16" 1
97 MIYD07.04.1.00661 CHAIN LOOP - 53EX91VXL 1
98 MIYD07.04.1.00101 GUIDE BAR - 140SDEA041 1
99 MIYD38-3.08.01-00 PLUG WRENCH 1
100 MIYD38-3.08.04-00 5/32 FILE 1
101 MIYD20-WAT CARB KIT (D20-WAT) 1
ID PART NUMBER DESCRIPTION QTY
1 MIYD38-5.04.00-00 CHAIN BRAKE ASSEMBLY 1
2 MIYD38-3.04.00-16 SCREW M5X40 1
3 MIYD38-3.04.00-13 SLEEVE 1
4 MIYD38-3.04.00-12 SLEEVE 1
5 MIYD38-5.04.00-2 CHAIN BRAKE LEVER 1
6 MIYD38-3.04.02-00 BRACKET 1
7 MIYD38-3.04.00-7 SPRING 1
8 MIYD38-3.04.00-9 CHAIN BRAKE TORSION SPRING 1
9 MIYD38-3.04.00-14 WASHER 5.2X23X1.2 1
10 MIGB/T6183.1 M5 NUT M5 1
11 MIYD38-3.04.00-6 CAP 1
12 MIYD38-3.04.00-5 COMPRESSION SPRING 1
13 MIYD38-3.04.00-15 TENSIONER COVER PLATE 1
14 MIGB/T119.2 3X14 PIN 3X14 1
15 MIYD38-3.04.00-4 BLOCK 1
16 MIYD38-3.04.00-3 ACTUATOR 1
17 MIGB/T119.2 3X9 PIN 3X9 3
18 MIYD38-3.04.00-11 BRAKE CONTROL ROD 1
19 MIYD38-3.04.00-8 BRAKE SPRING 1
20 MIYD38-3.04.00-10 BRAKE BAND 1
21 MIGB/T845 ST4.2X9.5 TAPPING SCREW ST4.2X9.5 5
22 MIYD38-3.04.00-1 COVER PLATE 1
24 MIYD45.04.00-26 TENSIONER GEAR 1
25 MIYD45.04.00-24 TENSIONER SCREW 1
26 MIYD45.04.00-25 TENSIONER PAWL 1
27 MIGB/T6177.1 M8 NUT M8 2
28 MIYD38-3.05.01-00 AIR FILTER LOCK NUT 1
29 MIYD38-3.05.00-6 LOCK NUT WASHER 15X26X1 1
30 MIYD38-5.05.00-2 AIR FILTER COVER 1
31 MIYD38-5.01.08.00-00 AIR FILTER 1
32 MIYD38-5.05.00-1 UPPER COVER PLATE 1
33 MIYD38-3.05.00-5 VENT BAFFLE 1
34 MIYD38-3.05.00-4
CUSHION 1
35 MIGB/T845 ST4.8X16 TAPPING SCREW ST4.8X16 12
36 MIYD38-3.00.00-7 DUST SHIELD 1
37 MIYD38-3.00.00-11 CHOKE LEVER RETAINING 1
38 MIYD38-3.00.00-10 CHOKE LEVER 1
39 MIYD38-5.02.00-1 SIDE PLATE 1
40 MIYD38-5.12.00-00 RECOIL STARTER ASSEMBLY 1
41 MIGB/T845 ST4.8X13 TAPPING SCREW ST4.8X13 1
42 MIGB/T96 M5 WASHER M5 1
43 MIYD38-5.12.00-6 RETAINER 1
44 MIYD38-5.12.00-5 TENSION SPRING 1
45 MIYD38-3.02.00-6 RECOIL ROPE 3X920 1
46 MIYD38-7.02.00-4 STARTER PULLEY (NEW STYLE) 1
47 MIYD36.02.01-2 RECOIL SPRING HOLDER 1
