CS38 SELECT - Engine Unit Parts List
ID PART NUMBER DESCRIPTION QTY
1 MIYD38-3.01.00-1 CYLINDER 1
2 MIGB/T6185.1 M5 NUT M5 2
3 MIGB/T93 M5 SPRING WASHER M5 11
4 MIGB/T97.1 M5 WASHER M5 10
5 MIGB/T2672 M5X14 SCREW M5X14 1
6 MIYD38-3.01.09.00-1 MUFFLER COVER PLATE 1
7 MIYD38-3.01.09.00-00 MUFFLER 1
8 MIYD38-3.01.00-6 MUFFLER GASKET 1
9 MIYD38-3.01.00-10 MUFFLER CONNECTING SCREW 1
10 MIGB/T6191 M5X20 SCREW M5X20 4
11 MIYD38-3.01.11.05-00 SPARK PLUG 1
12 MIYD38-3.01.00-7 AIR INTAKE TUBE GASKET 1
13 MIYD38-3.01.00-3 AIR INTAKE TUBE 1
14 MIYD38-3.01.00-8 CARBURETTOR GASKET 1
15 MIYD38-3.01.00-5 CYLINDER GASKET 1
16 MIYD38-3.01.03.00-2 PISTON RING 1
17 MIYD38-3.01.03.00-3 PISTON PIN 1
18 MIYD38-3.01.03.00-4 PISTON PIN CIRCLIP 2
19 MIYD38-3.01.03.04-00 PISTON 1
20 MIYD38-3.01.03.00-5 NEEDLE BEARING RING 2
21 MIYD38-3.01.03.02-00 NEEDLE BEARING 10X14X11 1
22 MIYD38-3.01.03.01-00 CRANKSHAFT 1
23 MIGB/T1099 3X3.5X10 SEMI-CIRCULAR KEY 3X3.5X10 1
24 MIYD38-3.01.01.00-1 L/H CRANKCASE 1
25 MIGB/T276 6201D BEARING 6201 GRADE D 12X32X10 2
26 MIYD38-3.01.01.00-3 CRANKCASE GASKET 1
27 MIYD38-3.01.01.00-2 R/H CRANKCASE 1
28 MIGB/T893.1 32 CIRCLIP 32 1
29 MIYD38-3.01.01.01-00 OIL SEAL 12X32X5.5 1
30 MIGB/T6191 M5X30 SCREW M5X30 4
31 MIGB/T900 M8X26-8.8 DOUBLE-SCREW BOLT AYM8-M8X26-8 2
32 MIYD45.01.00-21 FELLING SPIKE 1
33 MIGB/T2672 M5X12
SCREW M5X12 1
34 MIYD38-3.01.00-15 CHAIN CATCHER 1
35 MIYD38-3.01.00-16 CHAIN CATCHER SCREW 1
36 MIYD38-3.01.00-4 DAMPER 1
37 MIGB/T2672 M4X10 SCREW M4X10 1
38 MIYD38-3.01.01.02-00 OIL SEAL 12X22X7 1
39 MIYD38-3.01.11.01-00 IGNITION COIL 1
40 MIGB/T2672 M4X14 SCREW M4X14 6
41 MIGB/T93 M4 WASHER M4 2
42 MIYD38-3.01.11.02-00 GROUND WIRE 1
43 MIGB/T6177.2 M8X1 NUT M8X1 1
44 MIYD38-3.01.10.00-00 FLYWHEEL ASSY 1
45 MIYD38-3.01.13.00-00 CLUTCH ASSEMBLY 1
47 MIYD38-3.01.13.01-3 CLUTCH EXTENSION SPRING 1
49 MIYD38-3.01.13.00-2 CLUTCH WASHER 1
50 MIYD38-3.01.13.00-1 CLUTCH DRUM 1
51 MIYD38-3.01.00.01-6 NEEDLE BEARING 10X13X13 1
52 MIYD38-3.01.00-11 WORM DRIVE 1
53 MIYD38-3.00.00-12 COVER PLATE 1
54 MIYD38-3.01.15.00-00 OIL PUMP 1
55 MIYD38-3.01.00-13 OIL FEED PIPE 3X6.5X80 1
56 MIYD38-3.01.00-12 WORM WASHER 10X18X1 1
57 MIYD38-3.00.00-2 OIL FEED PIPE 3.3X6.5X68 1
58 MIYD38-3.00.00-17 OIL PIPE CIRCLIP 2
59 MIYD38-3.00.00-3 BAYONET 1
60 MIYD38-3.00.00-16 OIL FILTER ASSEMBLY 1
63 MIYD38-3.01.00-14 SPRAY NOZZLE 1
